Hello everyone, this is the third article in the series about computers, and also the last one with this header here, because from here on it’s recommended that you have already read the two previous articles:

Loading the Elevenlabs Text to Speech AudioNative Player...

In the previous articles, we saw how logic gates can be used to make comparisons and also calculate arithmetic operations, but we haven’t yet seen how the computer can store information over time.

Another thing we’ll do here is categorize each type of chip: the ones shown previously are combinational, which means they don’t need anything beyond signals at their inputs to be able to compute a result, but there are also sequential ones. The difference between them is that sequential depends not only on the input signals, but also on the previously processed value.

A very practical way to use logic gates to store information is using a chip called flip-flop, which is represented below. It contains 2 inputs: the top one set and the bottom one reset (you can click on the circuit below to interact with them).

Interactive
If you stop to analyze, it’s quite simple: following the set trail, you’ll see there are two logic gates in the path, an OR and an AND. One of the OR gate inputs is connected to the result of the AND at the end of the chip. This combination makes it so that when we have 0 and are given a value 1, the OR gate will result in 1, and the AND will also.

However, when we remove the signal from set, the value that was previously placed is persisted because now the OR is maintaining the state that keeps the AND also in the previous state. Problem solved, right? No! Notice that our circuit is now locked, as there’s no way to get out of this state unless the AND gets another value, and that’s what the reset gate is for: it’s connected to a NOT, meaning while it’s off (0), its result will be 1 (on), and vice versa.

An evolution we can make to the flip-flop is to transform it into a Register. In the register, we can choose whether it’s time or not to read our signal and store it, and subsequently rewrite it, all at our leisure. There are many ways to achieve this chip, so I’ll use the implementation demonstrated by Sebastian Lague.

In it, we just need to add 3 more logic gates and that’s it!

Interactive
If we break it down a bit, what happens is the following: the upper input, which we’ll now call data, will only be saved in the flip-flop when the lower input, which also changed names, now called enabled. So instead of using two inputs, one to save and another to erase, this combination of ANDs and NOT chooses which operation will be performed.

  • If data = 1 and enabled = 1, then it’s the same as turning on the set input of the flip-flop.
  • If data = 0 and enabled = 1, then it’s the same as turning on the reset input of the flip-flop. Notice that enabled always needs to be activated so that it can save the signal that was placed in data.

Another thing we can do is take inspiration from the previous article, where at the end we learned that if we combine several Adders, we can do calculations with multiple digits. In memory it’s the same way: combining several registers, you can provide an input for each data and share the enabled signal, and thus you can save the values of an entire binary number.

For now, we say goodbye here, see you next time 😄
